An implementation of anaglyphs stereoscopic multiplexing that is based on linear operations. More...
#include <LinearAnaglyphsMultiplexer.hh>
Classes | |
| struct | Impl |
Public Member Functions | |
| void | setLeftColor (gmCore::float3 c) |
| Sets the color of the left eye filter, in RGB 0-1. More... | |
| void | setRightColor (gmCore::float3 c) |
| Sets the color of the right eye filter, in RGB 0-1. More... | |
| void | setSaturation (float s) |
| Sets the saturation of color to use in the final image, in the range 0-1. More... | |
| void | setLeftSaturation (float s) |
| Sets the saturation of color to use for the left eye, in the range 0-1. More... | |
| void | setRightSaturation (float s) |
| Sets the saturation of color to use for the right eye, in the range 0-1. More... | |
| size_t | getEyeCount () |
| Returns the number of eyes that should be rendered for the multiplexer. More... | |
| void | prepare () override |
| Prepares the multiplexer for rendering to the two eyes. More... | |
| void | setupRendering (size_t eye) override |
| Sets up rendering for one eye at a time. More... | |
| void | finalize () override |
| Finalizes the multiplexing. More... | |
 Public Member Functions inherited from gramods::gmGraphics::MultiscopicMultiplexer | |
| virtual std::string | getDefaultKey () override |
| Returns the default key, in Configuration, for the Object. More... | |
| Public Member Functions inherited from gramods::gmCore::Object | |
| Object () | |
| Initializes internal data. More... | |
| virtual | ~Object () |
| Cleaning up internal data. More... | |
| virtual void | initialize () |
| Called to initialize the Object. More... | |
| virtual void | accept (Visitor *visitor) |
| Calls the visitors apply method with this as argument. More... | |
| virtual void | traverse (Visitor *visitor) |
| Calls the child Object's accept method, if such exist. More... | |
| bool | isInitialized () |
| Returns true if the Object is initialized. More... | |
Static Public Attributes | |
| static gramods::gmCore::OFactory::OFactoryInformation | _gm_ofi |
Detailed Description
An implementation of anaglyphs stereoscopic multiplexing that is based on linear operations.
Member Function Documentation
◆ finalize()
|
overridevirtual |
Finalizes the multiplexing.
Implements gramods::gmGraphics::MultiscopicMultiplexer.
◆ getEyeCount()
|
inlinevirtual |
Returns the number of eyes that should be rendered for the multiplexer.
Returns the value two (2).
Implements gramods::gmGraphics::MultiscopicMultiplexer.
◆ prepare()
|
overridevirtual |
Prepares the multiplexer for rendering to the two eyes.
Implements gramods::gmGraphics::MultiscopicMultiplexer.
◆ setLeftColor()
| void gramods::gmGraphics::LinearAnaglyphsMultiplexer::setLeftColor | ( | gmCore::float3 | c | ) |
Sets the color of the left eye filter, in RGB 0-1.
Default is red (1, 0, 0).
XML-attribute: leftColor
◆ setLeftSaturation()
| void gramods::gmGraphics::LinearAnaglyphsMultiplexer::setLeftSaturation | ( | float | s | ) |
Sets the saturation of color to use for the left eye, in the range 0-1.
Removing some saturation reduces the problem that an object with the same color as the eye filter becomes invisible for that eye. Default is 0.8.
XML-attribute: leftSaturation
◆ setRightColor()
| void gramods::gmGraphics::LinearAnaglyphsMultiplexer::setRightColor | ( | gmCore::float3 | c | ) |
Sets the color of the right eye filter, in RGB 0-1.
Default is cyan (0, 1, 1).
XML-attribute: rightColor
◆ setRightSaturation()
| void gramods::gmGraphics::LinearAnaglyphsMultiplexer::setRightSaturation | ( | float | s | ) |
Sets the saturation of color to use for the right eye, in the range 0-1.
Removing some saturation reduces the problem that an object with the same color as the eye filter becomes invisible for that eye. Default is 0.8.
XML-attribute: rightSaturation
◆ setSaturation()
| void gramods::gmGraphics::LinearAnaglyphsMultiplexer::setSaturation | ( | float | s | ) |
Sets the saturation of color to use in the final image, in the range 0-1.
Removing some saturation reduces the problem that an object with the same color as the eye filter becomes invisible for that eye. Default is 0.8.
XML-attribute: saturation
◆ setupRendering()
|
overridevirtual |
Sets up rendering for one eye at a time.
Implements gramods::gmGraphics::MultiscopicMultiplexer.
The documentation for this class was generated from the following files:
- /home/karlu/private/program/gramods/modules/gmGraphics/include/gmGraphics/LinearAnaglyphsMultiplexer.hh
- /home/karlu/private/program/gramods/modules/gmGraphics/src/LinearAnaglyphsMultiplexer.cpp
