A renderer that draws an obj file. More...
#include <ObjRenderer.hh>
Classes | |
| struct | Impl |
| struct | Material |
| Data struct for material data used in the obj file rendering. More... | |
Public Member Functions | |
| void | initialize () override |
| Called to initialize the Object. More... | |
| void | render (const Camera &camera, const Eigen::Affine3f &Mm) override |
| Performs rendering of 3D objects in the scene. More... | |
| void | getNearFar (const Camera &camera, const Eigen::Affine3f &Mm, float &near, float &far) override |
| Extracts the currently optimal near and far plane distances. More... | |
| void | setFile (std::filesystem::path file) |
| Set the obj file to render. More... | |
| void | setRecenter (bool on) |
| Set to true if the model should be recentered after loading. More... | |
| std::vector< Material > | getMaterials () const |
| Returns the currently loaded materials. More... | |
| void | setMaterials (const std::vector< Material > &materials) |
| Sets the materials to use. More... | |
| std::vector< float > | getIntersections (const IntersectionLine &line) override |
| Check and return intersections between the provided line and the shape represented by this node. More... | |
 Public Member Functions inherited from gramods::gmGraphics::Renderer | |
| void | addEye (Eye e) |
| Add an eye to render to. More... | |
| Public Member Functions inherited from gramods::gmGraphics::Node | |
| virtual std::string | getDefaultKey () override |
| Returns the default key, in Configuration, for the Object. More... | |
| Public Member Functions inherited from gramods::gmCore::Object | |
| Object () | |
| Initializes internal data. More... | |
| virtual | ~Object () |
| Cleaning up internal data. More... | |
| virtual void | accept (Visitor *visitor) |
| Calls the visitors apply method with this as argument. More... | |
| virtual void | traverse (Visitor *visitor) |
| Calls the child Object's accept method, if such exist. More... | |
| bool | isInitialized () |
| Returns true if the Object is initialized. More... | |
Static Public Attributes | |
| static gramods::gmCore::OFactory::OFactoryInformation | _gm_ofi |
| Static Public Attributes inherited from gramods::gmGraphics::Renderer | |
| static gramods::gmCore::OFactory::OFactoryInformation | _gm_ofi |
Additional Inherited Members | |
| Public Types inherited from gramods::gmGraphics::Node | |
| typedef std::vector< std::shared_ptr< Node > > | list |
| Protected Attributes inherited from gramods::gmGraphics::Renderer | |
| std::set< Eye > | eyes |
| Eyes to render. More... | |
Detailed Description
A renderer that draws an obj file.
Member Function Documentation
◆ getIntersections()
|
overridevirtual |
Check and return intersections between the provided line and the shape represented by this node.
Reimplemented from gramods::gmGraphics::Node.
◆ getMaterials()
| std::vector< ObjRenderer::Material > gramods::gmGraphics::ObjRenderer::getMaterials | ( | ) | const |
Returns the currently loaded materials.
◆ getNearFar()
|
overridevirtual |
Extracts the currently optimal near and far plane distances.
This is typically used by a View if there are multiple renderers that need to be rendered with the same near and far planes for correct depth testing.
Implements gramods::gmGraphics::Renderer.
◆ initialize()
|
overridevirtual |
Called to initialize the Object.
This should be called once only!
Reimplemented from gramods::gmCore::Object.
◆ render()
|
overridevirtual |
Performs rendering of 3D objects in the scene.
Implements gramods::gmGraphics::Renderer.
◆ setFile()
| void gramods::gmGraphics::ObjRenderer::setFile | ( | std::filesystem::path | file | ) |
Set the obj file to render.
XML-attribute: file
◆ setMaterials()
| void gramods::gmGraphics::ObjRenderer::setMaterials | ( | const std::vector< Material > & | materials | ) |
Sets the materials to use.
The specified list must have the same length as the loaded material list.
◆ setRecenter()
| void gramods::gmGraphics::ObjRenderer::setRecenter | ( | bool | on | ) |
Set to true if the model should be recentered after loading.
Default is false.
XML-attribute: recenter
The documentation for this class was generated from the following files:
- /home/karlu/private/program/gramods/modules/gmGraphics/include/gmGraphics/ObjRenderer.hh
- /home/karlu/private/program/gramods/modules/gmGraphics/src/ObjRenderer.cpp
